Yamaha R6

The Yamaha R6 is your quintessential supersport motorcycle, packing a high-revving 599cc inline-four that delivers 118 hp at 14,500 rpm. You’ll appreciate its razor-sharp handling courtesy of the aluminum Deltabox frame, keeping weight at just 419 lbs. With a top speed of 162 mph and aggressive ergonomics, it’s built for carving corners and dominating track days. Later models offer sophisticated electronics to harness this thoroughbred’s potential.

Engine and Displacement of Yamaha R6

Inline-4, 599cc, liquid-cooled, DOHC, 16-valve

Chassis of Yamaha R6

Deltabox aluminum twin-spar frame

Wheels & Tires of Yamaha R6

Front: 120/70-ZR17, Rear: 180/55-ZR17, Radial sport tires

Transmission and Clutch of Yamaha R6

6-speed, multi-plate wet clutch, chain drive

Fuel System and Fuel Capacity of Yamaha R6

Electronic fuel injection, 17 liters (4.5 gallons)

Weight, Seat Height, Dimensions, Wheelbase

• Weight: 190 kg (419 lbs)
• Seat Height: 850 mm (33.5 inches)
• Dimensions: 2040×695×1150 mm (80.3×27.4×45.3 inches)
• Wheelbase: 1375 mm (54.1 inches)
• Ground Clearance: 130 mm (5.1 inches)

Top Speed and Technical Details of Yamaha R6

• Power: 118 hp/87.1 kW @ 14,500 rpm
• Torque: 61.7 Nm @ 10,500 rpm
• Bore × Stroke: 67.0 × 42.5 mm
• Compression ratio: 13.1:1
• Top speed: 260 km/h (162 mph)
• Rake/Trail: 24° / 97 mm

Summary of Yamaha R6

The Yamaha R6 is a high-performance 599cc supersport motorcycle featuring an aluminum Deltabox frame and a lightweight inline-four engine.

• Distinguished by its aggressive bodywork with dual headlights and underseat exhaust (pre-2017), the R6 underwent significant revisions in 2006, 2008, and 2017.
• Later models incorporate ride-by-wire throttle, multiple riding modes, and traction control.
• Commonly replaced parts include fairings, mirrors, radiators, and clip-on handlebars due to crash damage.
• The frame-stamped VIN can be found on the steering head, while the engine number is located on the right crankcase.
• Fairings and electronics aren’t universally compatible between generations, making model year verification critical for parts interchangeability.

Match Yamaha R6 Parts to the Exact Model Year

The YZF-R6 changed considerably across its production generations. Fairings, headlights, subframes, airboxes, instruments and electrical components are not universally interchangeable. Supply the model year, VIN or compliance-plate details, engine number and any visible part number, together with photographs of the component and its mounting points.

Check Fairings, Electronics and Crash-Prone Components

For bodywork, confirm the side, colour, mounting tabs and whether infill panels or brackets are included. ECUs, instruments, ignition parts and wiring looms need matching identifiers and connector photographs. Forks, wheels, brakes, rearsets and clip-ons should be checked for straightness, damaged threads and previous repairs rather than judged only by cosmetic condition.

Yamaha R6 Enquiries Across Sydney

Send the required part, model year and photographs before arranging travel or transport. For a damaged or non-running R6, include the Sydney suburb, whether the motorcycle rolls, key availability, missing components and access conditions. Fitment, condition and current availability can then be reviewed against the information supplied.

For other Yamaha models, visit our Yamaha motorcycle parts in Sydney page.
